TE Connectivity
Wire Termination Technologies
Leg Spring
Intended for use
in more rugged
applications such
as instrumentation,
industrial controls, data
acquisition, security
& alarm, and HVAC
products. Provides for
faster wire termination
than screw versions.
Crimp Style
A terminal block
plug that utilizes
an insertable crimp
snap contact for wire
termination. This
plug will mate to
standard headers on
5.08mm. Intended for
use in higher volume
applications. Used in
conjunction with junior
power timer contacts.
Wire Protector
Version
Recommended for
low cost commercial
applications. Intended
for use in lighter
duty or commercial
applications such as
security and alarm
systems or HVAC
controls. Prevents the
screw from damaging
the wire!
te.com/products/eurostyle
Euro Style Terminal Blocks
Insulation
Displacement
Intended for
use in industrial
communications and
control applications
such as analog or serial
communications using
22-24 awg wire. Pivot
block plug mates with
3.5mm horizontal and
vertical terminal block
headers.
Rising Cage
Intended for use
in more rugged
applications, such as
industrial controls,
data acquisition and
communications
products, where
multiple wire
terminations are
required. Available
in one piece and two
piece configurations.
Front Style
Screw Clamp
The key feature of this
style of terminal block
plug is that the wire
entry cavity and the
activating screw head
are on the same plane
which is parallel to the
plug in direction. This
will mate with vertical
and right angle headers.
